ganban

git-based Kanban TUI

What is this?

Note: this is the plan. half of this isn’t working yet. half of it is, and I’m not saying which half.

ganban is a Kanban board that lives in git. It sits in an orphan branch so web UIs don’t offer to merge it. In ganban, our tasks stay with the code and we don’t need to rely on external services and API keys. It’s just files in a dir.

The board’s columns are directories named id.slug like 1.backlog. They don’t need a numeric id, they’re ordered alphanumerically so the TUI has the same order as ls -l. The TUI will renumber them for you if you move columns around.

Cards on a board are symlinks to Markdown docs in the ./.all dir, which holds the actual data. The links are ordered in the same way as cards. Keeping them in .all gives them stable IDs, so you can link to them. ganban will round up stray files and replace them with a link, so you don’t need to remember ln’s weird syntax.

The first # heading, if it’s present, will override the title of a card. Any ## subheading becomes a section, and the TUI can choose a custom editor for sections with special names. This is how comments and todo lists work.

You can also add metadata like labels, a due date, assignee, story points - or anything else you like - using front-matter. Metadata works on columns too, by editing the index.md file in their dir. And the board of course, which can have a title and settings in its metadata.

When running as a service, ganban will sync from remotes that the repo has, periodically pushing to upstream and resolving conflicts the best it can. This creates a kind of mesh network for your board.

If you don’t like the terminal, you can use the web UI (which looks just like the TUI.) If you’re a robot that isn’t good at UIs, ganban -d will sync in the background as you work. If the daemons haunt you, ganban --sync for manual syncing. If you’re a bot, there’s context-friendly instructions for use in the board’s default index.md.

Overview

Open a repo with ganban and it reads from a ganban orphan branch. The board is just directories (columns) containing symlinks (cards) pointing to canonical card files. Everything is plain markdown, works with any text editor, and syncs via git.

Data Model

Cards

Canonical card files live in .all/ with 3-digit numeric IDs:

.all/
  001.md
  002.md
  003.md

Card format:

# Title of the card

Main description goes here, displayed in the body.

## Notes

Subsequent sections become sidebar panels in the TUI.

## Comments

**@user 2024-01-15**: Append-only, TUI adds name + date automatically.

## Links

- blocks [#42](../.all/042.md)
- see also [#7](../.all/007.md)

Tags on separate lines for clean merges:

tags:
 - first
 - second

Columns

Directories with 1-digit numeric prefix for ordering:

1.backlog/
2.in-progress/
3.done/

Board Layout

Cards appear in columns as symlinks with 2-digit position prefix:

1.backlog/
  01.fix-login-bug.md -> ../.all/001.md
  02.add-feature.md -> ../.all/003.md
2.in-progress/
  01.refactor-api.md -> ../.all/002.md

Numbering

Default digits: 3 for .all/, 1 for columns, 2 for symlinks. Can extend with hex or base64 if needed, but integers are the default.

Git Integration

Reading/Writing Without Checkout

Operates on the ganban branch without checking it out, using git plumbing:

Sync Workflow

  1. Commit before pull (TUI enforces this)
  2. git pull --rebase on tasks branch
  3. Reload board
  4. If conflicts, show conflict UI

Conflict Handling

Multi-Remote Sync

Philosophy
